Questions for Figure 13, part A

Instructions: Answer the matching questions, by entering an item in the left column. If the answer is correct, it will be copied into the adjacent box; otherwise an error will appear in the box. (When all of your answers are filled in and correct, the page background will change colors.)

This quiz is for your own practice only; no record of your progress is kept or reported to anyone.

156. Structure #113 157. Structure #114 158. Structure #115 159. Structure #116 160. Structure #117 161. Structure #118 162. Structure #119 163. Structure #120 164. Structure #121 165. Structure #122 166. Structure #123 167. Structure #124 168. Structure #125 169. Structure #126 170. Structure #127 171. Structure #128 172. Structure #129

1. Amygdala 2. Anterior commissure 3. Arcuate nucleus of the hypothalamus 4. Caudate body 5. Corpus callosum 6. Dorsomedial nucleus of the hypothalamus 7. Dorsomedial nucleus of the thalamus 8. Fornix body 9. Globus pallidus 10. Lateral hypothalamus with medial forebrain bundle 11. Mammillary nucleus 12. Mammillothalamic tract 13. Optic tract 14. Postcommissural fornix 15. Posterior limb -internal capsule 16. Putamen 17. Stria terminalis & terminal vein 18. Ventral lateral nucleus of the thalamus 19. Ventromedial nucleus of the hypothalamus

Possible points: 17

Freeware programming origninally provided by Think Again Quiz Maker
and modified in the Multimedia Scriptorium. Questions provided by Dr. C. Tsuchitani.
